產品介紹
特氟龍（聚四氟乙烯）玻纖布膠帶
PTFE Glass Cloth Tape
性能及應用領域
Specification and Application
該膠帶以鐵氟龍玻璃纖維布為基材，涂布高性能壓敏硅膠。鐵氟龍膠帶表面光滑，有著良好的抗粘性，耐化學腐蝕和耐高溫性以及優秀的絕緣性能；表面摩擦系數小，絕緣性好，抗粘性好，容易清洗附著其表面的各種油漬，污點等。應用于電子電氣的絕緣，耐高溫包復材料，各種石油化工管道的抗腐蝕包復，或者是根據厚度的不同用于各種烘干機械設備的傳送帶，粘合帶。
This tape is consist of PTFE glass cloth and high performance high temperature resistant silicone adhesive. It has smooth surface, excellent anti-adhesion, good corrosion resistance wide range temperature resistant, excellent insulation ability and low surface friction coefficient. It is widely used in high temperature resistance and anti-corrosion wrapping, conveyor belt of drying equipment.
特氟龍（聚四氟乙烯）玻纖布膠帶參數表
PTFE Glass Cloth Tape Technical Data
型號 Model | 基材 Backing | 膠黏劑 Adhesive | 標準尺寸 Standard Size | 一般特性 General Characteristics | ||||
材質 Material | 顏色 Color | 厚度 Thickness (MM) | 規格 Specification | 粘著力 Adhesion Force (N/25MM) | 伸長率 Elongation (%) | 耐溫性 Temperature Resistant (℃) | ||
ZCPG-A | 聚四氟乙烯復合玻璃布 PTFE Glass Cloth | 棕色/黑色 Brown/Blaci | 硅膠 Silicone | 0.13/0.18 | 5MM-500MM*10M | 6 | 4 | 260 |
ZCPG-B | PTFE Film | 棕色/黑色 Brown/Blaci | 硅膠 Silicone | 0.13/0.18 | 5MM-500MM*10M | 6 | 30 | 260 |
(1) 試驗環境為溫度 23±5℃及溼度 55±10%RH。
(2) 建議操作環境為 10℃~35℃。
(3) 勿置于高溫、潮濕及日照處。
(4) 適當環境下，保存期限一年。
(5) 使用前請先測試，以免被貼物表面不穩定物質影響膠性。
說明：以上諸項技術指標乃本公司采用公認可靠方法檢驗的平均數據，為確保正確使用本公司產品，請您基于使用對象，先行對使用目的與條件做詳盡了解，以便我司為您提供準確產品。
Note:Above data are based on the tests of acknowledged methods. In order to using our product correctly, please check the data and understand your application purpose first. After that, we will recommend the most suitable products.
