產品介紹
PET硅膠帶
PET Silicone Tape
性能及應用領域
Specification and Application
用于烤漆工藝，PCB焊錫，電鍍，靜電噴涂，粉末噴涂等耐溫的用途，撕起來不會殘膠，且不易斷裂，烤漆邊緣為整齊直線，具有抗紫外線功能，表面平整，具有很好的柔軟性和服帖性，同時具有很好的保持力、耐候性及耐高溫性能（260攝氏度），可定制33M-500M.
This product consist of polyester film and silicone adhesive, it has good adhesion force, high temperature resistant (260C/500F), no residues after peeling off. It mainly be used in high temperature masking protection, such as stoving varnish, electroplating, powder coating, electrostatic coating, PCB soldering, etc.Can be customized 3M-500M.
PET硅膠帶參數表
PET Silicone Tape Technical Data
Model | 基材 Backing | 膠黏劑 Adhesive | 標準尺寸 Standard Size | 一般特性 General Characteristics | ||||
材質 Material | 顏色 Color | 厚度 Thickness (MM) | 規格 Specification | 粘著力 Adhesion Force (N/25MM) | 伸長率 Elongation (%) | 耐溫性 Temperature Resistant (℃) | ||
ZCG-6 | 聚酯薄膜Polyester Film | Various | 硅膠 Silicone | 0.06 | 3MM-500MM*33M | 6 | 50 | 180 |
ZCG-8 | 聚酯薄膜Polyester Film | 各種 Various | 硅膠 Silicone | 0.08 | 3MM-500MM*33M | 8 | 52 | 180 |
ZCG-9 Connecting tape | 聚酯薄膜Polyester Film | 各種 Various | 硅膠 Silicone | 0.09 | 3MM-500MM*33M | 10-13 | 60 | 180 |
(1) 試驗環境為溫度 23±5℃及溼度 55±10%RH。
(2) 建議操作環境為 10℃~35℃。
(3) 勿置于高溫、潮濕及日照處。
(4) 適當環境下，保存期限一年。
(5) 使用前請先測試，以免被貼物表面不穩定物質影響膠性。
說明：以上諸項技術指標乃本公司采用公認可靠方法檢驗的平均數據，為確保正確使用本公司產品，請您基于使用對象，先行對使用目的與條件做詳盡了解，以便我司為您提供準確產品。
Note:Above data are based on the tests of acknowledged methods. In order to using our product correctly, please check the data and understand your application purpose first. After that, we will recommend the most suitable products.
